Colour: Blue
At a glance
Key specifications.
- Engine displacement
- 109 cc
- Maximum power
- 4.5 kW @ 7,500 rpm
- Starting system
- Electric and kick
SpecificationsEngine, chassis and dimensions
Specifications sourced from the manufacturer. Confirm current details with a branch before making a decision.
Engine
- Engine type
- 4-stroke, 2-valve, single-cylinder
- Engine displacement
- 109 cc
- Bore × stroke
- 50 × 55.5 mm
- Compression ratio
- 9.5:1
- Maximum power
- 4.5 kW @ 7,500 rpm
- Maximum torque
- 7 Nm @ 5,000 rpm
- Lubrication system
- Pressure splash
- Starter
- Electric and kick
- Ignition
- CDI
Transmission
- Clutch type
- Wet multi-plate
- Transmission type
- Manual, 4-speed
- Final drive
- Chain
Chassis
- Frame
- Arch bar truck
- Front suspension
- KYB telescopic fork
- Rear suspension
- Telescopic coil spring, oil damped
- Front brake
- 110 mm drum
- Rear brake
- 110 mm drum
- Front tyre
- 70/90-17, tubeless
- Rear tyre
- 80/90-17, tubeless
Dimensions
- Overall length
- 1,930 mm
- Wheelbase
- 1,250 mm
- Seat height
- 760 mm
- Ground clearance
- 125 mm
- Fuel capacity
- 4 L
- Kerb weight
- 100 kg
