Choose a version
Colour: Vigorous Blue
At a glance
Key specifications.
- Engine displacement
- 108 cc
- Maximum power
- 6.6 hp @ 8,000 rpm
- Starting system
- Electric & Kick Starter
About this model
Built for more journeys.
Introducing the 2023 Ikon Rakyat, and the All NEW Kriss 110 Disc Brake. Now equipped with an Electronic Fuel Injection system that complies with EURO 4 standard.
SpecificationsEngine, chassis and dimensions
Specifications sourced from the manufacturer. Confirm current details with a branch before making a decision.
Engine
- Engine displacement
- 108 cc
- Engine type
- Single-Cylinder SOHC 2-Valve
- Bore × stroke
- 50.0 x 55.0 mm
- Compression ratio
- 9.0:1
- Cooling system
- Air-Cooled
- Fuel system
- Carburetor Spica
- Maximum power
- 6.6 hp @ 8,000 rpm
- Maximum torque
- 6.7 Nm @ 6,000 rpm
Transmission
- Transmission
- 4-Speed Rotary
- Clutch type
- Wet Multi-plate Centrifugal Automatic
- Final drive
- Chain
- Starting system
- Electric & Kick Starter
Chassis
- Frame type
- Steel Tube Backbone
- Front suspension
- Telescopic Fork
- Rear suspension
- Twin Coil Spring Rear Shocks
- Front brakes
- Hydraulic Single Disc
- Rear brakes
- Drum Brake or Disc Brake
- Front tyre
- 70/90-17
- Rear tyre
- 80/90-17
Dimensions
- Overall length
- 1,900 mm
- Overall width
- 685 mm
- Overall height
- 1,100 mm
- Wheelbase
- 1,235 mm
- Ground clearance
- 145 mm
- Seat height
- 760 mm
- Kerb weight
- 97 kg
- Fuel capacity
- 4.2 L
Equipment & safety
- Ignition
- CDI
- Battery
- 12V 4.0Ah
- Headlight
- Halogen Headlamp
- Taillight
- Bulb
- Instrument cluster
- Analogue Speedometer with USB Port
- Rider aids
- USB Charging Port, Gear Indicator
- Safety & ABS
- Standard Disc / Drum
